IOTPS 5V 700mA Power Supply Module



IOTPS 5V 700mA Power Supply Module



IOTPS 5V 700mA Power Supply Module is an AC240V to DC 5V Step Down Module at 0.7A With temperature protection, over current protection and short circuit protection, high and low voltage isolation, AC85 ~ 265 v wide voltage input, ac/dc current , 431 precision voltage stability and DC5V output.

Features of IOTPS 5V 700mA Power Supply Module:

  • Input voltage: AC 85 ~ 265 v 50/60 hz or DC 100~ 370 v
  • Input current: 0.0273A(AC110V) 0.014A(AC220V)
  • Input Inrush Current: 20A
  • Output voltage: DC 5V (+ / – 0.2 V)
  • Output current 700 mA
  • Power 3.5 W
  • Operating temperature -20~60°
  • Relative humidity 40-90%RH
  • Output 5V, min current 0a, max current 700mA, peak current: 800mA, output range: 4.8~5.2v, ripple wave: 60mV
  • Output power:0-4W(DC current)
  • Output efficiency: 80%
  • Switch machine overshoot: MAX 10%
  • Output voltage rise time: MAX 100MS
  • Output over voltage: 4.8-5.2V, recovery: Lock, restart after recovery
  • Output over power protection: YES ,recovery: Lock, restart after recovery
  • Short-circuit protection: YES, automatic recovery after problem solved
  • Temperature protection: YES, recovery: Lock, restart after recovery
  • Overcurrent protection: YES, recovery: Lock, restart after recovery
  • Size: 21 x 32 x 19mm  Approximately.
  • IOTPS Dimensions:
www.graylogix.in














Location: Bengaluru, Karnataka, India
